EV ATLAS

Made in italy
General.ev_atlas

Optimise the work process with an industrial steam generator and vacuum cleaner 2-in-1.


A complete solution

EV ATLAS is an essential tool for any industrial environment that requires thorough and effective cleaning. It saves time, effort and resources while ensuring that the environment is disinfected and free from harmful microorganisms.


Real time-saver

EV ATLAS is a powerful steam generator designed to tackle heavy dirt, grease and grime in industrial environments. This innovative appliance combines the power of steam cleaning and vacuuming technology, thus, reducing the time for sanitation and disinfection by more than half.

Ease of execution

  • Intuitive controls and accessories make it easy
 to switch between cleaning modes.
    Intuitive controls and accessories make it easy to switch between cleaning modes.
  • A vacuum cleaner with high suction power that ensures even the
 smallest particles are removed from the surface.
    A vacuum cleaner with high suction power that ensures even the smallest particles are removed from the surface.
  • Manual steam power control for precise use.
    Manual steam power control for precise use.

Technical data

power supply
220 - 50 / 60 V - Hz
total power
3.2 kW
working pressure
10 bar / 145 Psi
boiler power
3.2 kW
steam production
140 g / 4.95 oz per min
power absorption
13 A / 220 V
start up time
10 min
boiler temperature
190 °C / 375 °F
boiler capacity
4 liters / 1.06 gallons
boiler material
type AISI 304
steam output regulation
electronic, manual steam control
water ejection
yes - continuous use
detergent ejection
yes - continuous use
water refill tank
5 liters / 1.32 gallons
detergent refill tank
5 liters / 1.32 gallons
body material
type - INOX AISI 304
weight net
22 kg / 88 lbs
dimensions
L-53 x W-37 x H-51
power cable length
5 m / 16.4 ft
steam hose length
5 m / 16.4 ft

Application areas

Attachment Kits

Fibreglass attachments with high durability and an easy-click system for a customer-friendly experience.

Steam Kit


Steam & Vacuum Kit


Additional accessories

Add customised attachments to your steam cleaning kit and tackle an even wider range of cleaning tasks with ease and efficiency.

Explore more

User Guide EV ATLAS

You can download the User Guide for EV ATLAS in Pdf. file by choosing your preferred language and get all the needed information about how to use the unit.
